• 2 Port HDMI Extender

2 Port HDMI Extender


Features



. Compact Size for OpticalHDMI Extender (HxWxD : 14.9mm x 40.5mm x 68.4mm )



. Duplex LC Receptacle Optical Interface



. Single-Mode and Multi-Mode Fiber Application



. Support Long Distance and High Resolution Image Transmission



. Support Video Resolution up to 3840x2160 / 30Hzfor UHD TV



. Self-EDID Programming Feature



. Indicate the Transmit and ReceiverSignal Status



. Single 5 V Power Supply



. Metal Enclosure and Low Power Consumption



. RoHS Compliant




Description

This Optical HDMI Extender is designed to transmit the HDMI signals to long distance through two fibers. It can be used not only multi-mode fiber but also single-mode fiber as system’s requirement. The EDID learning technology makes it more flexible and easier to installation for any variable resolution display. This Extender integrates all LED indicators, power supply input and Self-EDID button hole on the front panel. It will be easy and convenient to indicate the link status and to operate module.
